Dovetailer
l DVT-5B is a CNC Dovetail Machine. Users adjust tenon size and tool offset easily by simple humanity operation interface. The workpiece info files can be saved for repeated use.
l Equipped with MISTUBISHI servomotor, working precisely and durably.
l Cutter motor is high frequency motor imported from Italy, with good quality and durability.
l High order PLC makes working route proceeding without pause so finished tenons are smooth. Working efficiency and productivity are both improved.
l After users input workpiece size, the program calculates workpiece position automatically. Users put workpiece as the operation page indicates to shorten time for correcting.
l Multi-processing speed changing design. Users adjust working route speed of edge-trim, cutter-in, cutter-out according to different workpiece materials.
Model
DVT-5B
Max. working width
600 mm
Min. working width
50 mm
Max. working thickness
25mm
Min. working thickness
9mm
Cutterhead speed (rpm)
18000 rpm
Blade quantity
1
Main motor
3 HP
Machine size
1100×1750×1550 mm
Packing size
1520×1990×1410 mm
Net weight
650 kg
Gross weight
780kg
